GENERAL AVIATION AERODROME LIGHTS

Volume System offers certified battery-powered airport lights for general aviation airports, aerodromes, small domestic airstrips, airclubs and flying schools. The lights are certified and fully compliant with ICAO Annex 14. S4GA SP-102 portable airport lights are applicable for both paved and unpaved runways.

SP-102 PORTABLE AERODROME LIGHT

Certified aerodrome lighting
50 hrs of Autonomy
User-replaceable battery
Over 15 years lifespan
For general aviation airfields

TYPICAL APPLICATIONS

General aviation airport
Local aerodrome
Temporary runway & taxiway
Domestic airports
Grass airstrips

ICAO CERTIFIED AIRPORT LIGHTS

SP-102 Portable Airfield Lights are compliant with ICAO standards and certified by INTERTEK

APPLICABLE FOR DIFFERENT SURFACES

CONVERTIBLE TO SOLAR

SP-102 portable light can be easily converted to a fully autonomous solar runway light by adding 5W solar panel.

PORTABLE AERODROME LIGHTS

SP-102 PORTABLE RUNWAY EDGE LIGHT

OPTICS	LED type Type: omnidirectional Colour: white LED lifespan 100.000 hrs
AUTONOMY	25 hrs
OPERATING MODES	Steady / Flashing / Dusk till dawn* Visible / Infrared (optional) / Visible+Infrared (optional)
BATTERY	VRLA type, built-in User-replaceable Air-transportable
CHARGING	OCT-102 Charger Charging time – 8 hours Optional: 5W solar panel
CASING	Aluminium, glass dome Color: aviation yellow
DIMENSIONS (HEIGHT/DIAMETER)	210 x 125 mm
WEIGHT	2 kg
COMPLIANCE	ICAO, Annex 14th, Volume I, 7th Edition dated July 2016, clause 5.3.9.9 & Appendix 1, Figure A1-1b

SP-102 PORTABLE THRESHOLD LIGHT / RUNWAY END LIGHT

OPTICS	LED type Type: bidirectional, unidirectional Color: red/green, red, green LED lifespan 100.000 hrs
AUTONOMY	25 hours
OPERATING MODES	Steady / Flashing / Dusk till dawn* Visible / Infrared (optional) / Visible+Infrared (optional)
BATTERY	VRLA type, built-in User-replaceable Air-transportable
CHARGING	OCT-102 Charger Charging time – 8 hours Optional: 5W solar panel
CASING	Aluminium, glass dome Color: aviation yellow
DIMENSIONS (HEIGHT/DIAMETER)	210 x 125 mm
WEIGHT	2 kg
COMPLIANCE	ICAO, Annex 14th, Volume I, 7th Edition dated July 2016, clause 5.3.10.9/5.3.11.4 & Appendix 1, Figure A1-1b

SP-102 PORTABLE TAXIWAY LIGH

OPTICS	LED type, 11 cd light output Type: omnidirectional Colour: blue LED lifespan 100.000 hrs
AUTONOMY	105 hrs
OPERATING MODES	Steady / Flashing / Dusk till dawn* Visible / Infrared (optional) / Visible+Infrared (optional)
BATTERY	VRLA type, built-in User-replaceable Air-transportable
CHARGING	OCT-102 Charger Charging time – 8 hours Optional: 5W solar panel
CASING	Aluminium, glass dome Colour: aviation yellow
DIMENSIONS (HEIGHT/DIAMETER)	210 x 125 mm
WEIGHT	2 kg
COMPLIANCE	ICAO, Annex 14th, Volume I, 7th Edition dated July 2016

SP-102 PORTABLE OBSTRUCTION LIGHT, TYPE A, LOW INTENSITY

OPTICS	LED type, 37 cd light output Type: omnidirectional Colour: red LED lifespan 100.000 hrs
AUTONOMY	50 hrs
OPERATING MODES	Steady / Flashing / Dusk till dawn* Visible / Infrared (optional) / Visible+Infrared (optional)
BATTERY	VRLA type, built-in User-replaceable Air-transportable
CHARGING	OCT-102 Charger Charging time – 8 hours Optional: 5W solar panel
CASING	Aluminium, glass dome Colour: aviation yellow
DIMENSIONS (HEIGHT/DIAMETER)	210 x 125 mm
WEIGHT	2 kg
COMPLIANCE	ICAO, Annex 14th, Volume I, 7th Edition dated July 2016, Appendix 1, Figure A1-1b & Table 6-2, Type A
